ELAFLEX Hamburg
Coax hose assembling
V 16-1" cr
Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, yellow.
HB hot bitumen hose - loading plant
Hose Connection with TW coupling, TSG 3" Sight Glass
MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
ERV-G 50x160
Fuel mixer / blender
Elaflon Plus FEP 25
Universal hose ELAFLON PLUS FEP with seamless FEP lining, resistant to all commonly used chemicals, see resistance chart. Suitable for both suction and delivery (Type FEP D = delivery only). W.P. up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° C up to + 100° C, briefly up to 130° C. Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min (open system). Meets EN 12115.
HD-C Neon, large reel, VK 100 Ms, MB 100 Al
ERV-R 80.16 ZS 2
Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
ERV-G ... TW
"Yellow Band" Rubber Expansion Joints; tank truck
DGC-V 50 F SS for L.P. Gas, PN 25/40
Dry Disconnect Coupling with flange connection, DN 50, stainless steel, with rubber dust cap
M 21-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, blue.
Oasis CNG refuelling equipment:
Ultra Fast Fill System (Diagram, English)
DAC-V 65
Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading; detail
Rubber Expansion Joint ERV-R 80.16
RED BAND expansion joints for water, drinking water (approvalDVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature (depending on medium) - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.
Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion
Picture courtesy of Macoil International, Gibraltar
Vehicle refuelling with LPG (L.P. Gas, Autogas)
GasGuard GG30 BAYO nozzle with Bayonet connector and optional splashguard
ERV-R 200x175.16 ZS 4
Red Band Rubber Expansion Joint, special length 175 mm, with "ZS" limiter (tie rods with outer limitation in rubber bushings)
GasGuard GG11R
The GasGuard GG11 Back-Check Valve (GG11R: with additional release screw) should be standard equipment for any LPGas road tanker operator. It is used in conjunction with LPGas bulk refueling nozzles to contain leaks at storage tank fill points. If the fill point proves to be leaking when removing the nozzle it can be left on the tank until corrective action is taken. The driver can move to the next fill point without delay.
Slimline hose assembly, section view
IBC
with CHS chemical hose assembly
ELAPAC FD 50 Oval flange seal
Marine bunkering and cargo hoses
ship to ship cargo transfer
DAC-V 65
Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading
ELAFLEX quality: section view of a ERV bellows
Slimline 21 green
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.
Oasis TH Tank Head Valve, for CNG
ERV-W 80.16
WHITE BAND Rubber Expansion Joint for foodstuffs, also containing oil and fat. Liner corresponds to Recommendation XXI of BfR and FDA-21CFR 177.2600. Not approved for drinking water. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically non-conductive.
oasis TH104 Tank Head Valves, CNG trailer
Drum filling
with CHS chemical hose assembly
L.P.Gas home delivery:
LPG 38 hose assembly
