GasGuard nozzle GG 1 DN, hose assembly, nozzle boot NB-GG
SSB 32, SSB 25, SSB16
Safety Swivel Breaks (SSB)
Oasis FV103 45° Fill Valve with NC 203 P36 Nozzle, for CNG
Flexible bronze pipe connector BWO
Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps
Elaflex Pacific (Australia)
Road tanker reel with HD 50 hose assembly, ZV 500 nozzle
ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid
Stainless steel Hose Reel with pneumatic rewind system, HD 50
Manufacturing warm forged parts
Example SC 150 Spannloc clamp
Elaflon PTFE
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
ZVA Slimline 2 / ZVA Slimline 2 GR
Petrol station nozzles with (top) and without vapour recovery (below)
Sight Glasses for petrol station nozzles
SG 1" Al, SG-COAX, special types with Propeller
Automatic lathing machine, production of brass swivel parts
ERV-W 80.16 SS TA
White Band Rubber Expansion Joint with "TA" PTFE lining
Universal hose assembly
PCS 75 (Polypal Clean DN 75 mm) with MX 75-3" SS and DDC-M 80-3" SS Dry Disconnect Coupling
TW coupler MK 80 SS-90° (bent lever) and dust plug VB 80 ADR SS with pressure relief
Oasis HC308 Ultra Fast Quick Fill Coupler, SAE male, for CNG
AMKC 50 SS
'Camlock' stainless steel steel coupler to EN 14420 - 7 with hose tail and Spannloc clamps
Section view of a DS 2 swivel
ROTEX 80.16
Rubber Expansion Joint suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative
DCC Dry Cryogenic Coupling for LNG
Coupling process
Section view ERV-G Rubber Expansion Joint
Underwing refuelling A 380
Hose assemblies for petroleum based procucts
LTW 75, VX 80-3, MannTek DDC-M80-3Ms & TW 63, SFX 63 TW
PAL hose assemblies:
PCD 32 / RMC-SS, Butapal 32 / ACMX, Polypal Plus 50 / SFC 50 SS, Tecnopal 38 / MKX-SS, Pyropal 38 / MC38
PSB Pump Safety Break for High Hose Dispensers
Picture shows separation of the Slimline hose assembly after a drive-off accident
ELAFLEX Hamburg, narrow aisle stock for small parts
ELAFLEX refuelling equipment:
Quality is in the detail.
RS 2 x 78 SS
Reducer Female/Male
VK 50 SSE
TW male adapter. Material: stainless steel with universally resistant PFA coating (red)
