Cabinet of road tanker:

Cabinet of road tanker:

hose tubes, TW hoses, TW couplings

Production MannTek, Sweden

Production MannTek, Sweden

Requirements to a Hose

Requirements to a Hose

(German)

ERV TAS:

ERV TAS:

ERV with PTFE lining and PTFE vacuum support ring. Properties like type TA, but also suitable for vacuum service, up to 70° C.

HD 50 reel hose for petroleum based products, VC 50-2" Spannloc clamped male coupling

HD 50 reel hose for petroleum based products, VC 50-2" Spannloc clamped male coupling

ZV 500 for chemials

ZV 500 for chemials

Bulk filling of Methylene Chloride

ZVF 25 with EKG and GKG

ZVF 25 with EKG and GKG

Manual nozzle DN 25 for aircraft overwing refuelling, with ground cable assembly, dust cap assembly and AVGAS sticker (decal)

ELAFLEX Hamburg

ELAFLEX Hamburg

Assembling Spannfix hose clamps

Slimline quality dispensing hose for the forecourt

Slimline quality dispensing hose for the forecourt

SL 21 black

DDC-K ADR:

DDC-K ADR:

DDC Dust Caps with Pressure Relief Valve to ADR Requirements. These pressurized dust caps PN 10 of aluminium for DDC male adapters on road tankers are much lighter than the PN 25 versions of stainless steel.

Ship bunkering with STW hose assembly and MannTek DDC Dry Disconnect Couplings

Ship bunkering with STW hose assembly and MannTek DDC Dry Disconnect Couplings

Scandinavia

Production MannTek, Sweden

Production MannTek, Sweden

ZVF 50 helicopter refuelling

ZVF 50 helicopter refuelling

France

ZVA 25 with Z-Swivel

ZVA 25 with Z-Swivel

Boat Refuelling

Safety Swivel Break SSB 16 SS of stainless steel f. ZVA HV for AdBlue®

Safety Swivel Break SSB 16 SS of stainless steel f. ZVA HV for AdBlue®

new design

ZVF 50 JET

ZVF 50 JET

Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure PN 10 (140 psi). Temperature range - 40° C up to + 55° C.

ERV TA:

ERV TA:

ERV with white PTFE lining. Used when the chemical resistance of the chosen ERV type is insufficient. Resistant to all commonly used liquids. Electrically isolating, therefore not suitable for flammable liquids in Ex-Zones. Admissible working temperature of expansion joint has to be observed. For maximum pressure of 6 bar – not suitable for vacuum.

DDC-V 50 SS F

DDC-V 50 SS F

MannTek Dry Disconnect Coupling, DN 50, stainless steel, with flange connection

Ship cargo loading with FWS-PP composite hoses

Ship cargo loading with FWS-PP composite hoses

Offshore oilrig: TW hose assemblies, DDC Dry Disconnect Couplings

Offshore oilrig: TW hose assemblies, DDC Dry Disconnect Couplings

Oasis FV103 180° Fill Valve with Bus & Truck Nozzle, for CNG

Oasis FV103 180° Fill Valve with Bus & Truck Nozzle, for CNG

Hose Connection with TW coupling, TSG 3" Sight Glass

Hose Connection with TW coupling, TSG 3" Sight Glass

MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

AdBlue® urea solution, road tanker:

AdBlue® urea solution, road tanker:

DDC-M 50 Dry Disconnect Coupling, UTL 50 hose assembly on reel

ZVA Slimline 2 GR LA (with LeverAssist)

ZVA Slimline 2 GR LA (with LeverAssist)

LeverAssist hold-open aid for comfortable refuelling, for countries in which latching is not allowed

ZVA 25 with Z-Swivel

ZVA 25 with Z-Swivel

Boat Refuelling, Hose Reel

Dispenser, ZVA Slimline 2 and ZVA Slimline 2 GR nozzles

Dispenser, ZVA Slimline 2 and ZVA Slimline 2 GR nozzles

MC 100 SS female threaded hose coupling with Spannloc clamps

MC 100 SS female threaded hose coupling with Spannloc clamps

with universal hose UTL 100

ELAPHARM Type EPH 25

ELAPHARM Type EPH 25

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid

ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid

LeverAssist reduces the hold-open force by 90%, for comfortable refuelling in countries where latching is not allowed

LPG terminal: loading with DGC Dry Gas Couplings

LPG terminal: loading with DGC Dry Gas Couplings
