Unloading chemical road tanker

Tecnopal hose assembly, DDC Dry Disconnect Coupling, Guillemin adapter

Unloading petroleum products at the service station (road tanker to UST)

LTW hose assembly, MK 80-32° Ms couplers with bent lever. The lever shall always be fully closed for safety reasons. For applications with limited room.

Ship bunkering

HD hose assembly on dispenser vehicle

Fuel Grade Identification to EN 16942 for ZVA Nozzles

Type EK FGI

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Contour check

MB 50 TS SS Lockable fi ll pipe coupling

with VK 50 SS

ZVA Slimline 2 with reduced spout and Slimline hose

here: for gasoline, use in countries without vapour recovery regulation

Elaflex hoses

HD, TW, LPG, FXD, SL, FEP, CHS, LMS, UTS, PTFE, PCS

Ship bunkering with STW hose assembly and MannTek DDC Dry Disconnect Couplings

Scandinavia

ZVA Slimline 2 nozzles, ESB 16 Safety Breaks, Slimline hose assemblies

Paraguay

V 19-1" cr

Male ferrule hose coupling EN 14424, reusable. Slimline 19 SF (sulphur free) hose, black.

FGN 2 SS

Flange with male thread, stainless steel

KWZ 3" Al

Rail tanker adapter with male thread connection, aluminium

Underwing refuelling, HD-C hose assembly

VB 50 SSE

TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

Rubber Expansion Joint ERP 80.16

RED SPOT expansion joints for sanitary installations, highly flexible, for cold and warm water, pool water, sea water, drinking water. Temperature range (depending on medium) - 40° C up to + 90° C, temporarily up to + 120° C. Electrically dissipative.

LMS 50 Blue Band solvent hose with helix

Coupling: RMC 50 SS / SS, foodstuff thread, Spannloc clamps of stainless steel

AVKI 38 SSE

Camlock male adapter. Material: stainless steel with universally resistant PFA coating (red)

ZVA Slimline 2, guard 3, black scuffguard, blue colour sleeve

KW bronze corrugated pipe with cathodic protection

Cathodic protection flexible pipe connector (bronze corrugated pipe) for electrically insulating, cathodically protected installations. Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps - and directly underneath the dispensers

Rubber Expansion Joint ERV-R 80.16

RED BAND expansion joints for water, drinking water (approvalDVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature (depending on medium) - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.

FSH flame protection cover for ERV rubber expansion joints

Use e.g. in ship engine rooms

ZVF 50 JET overwing refuelling

with HD-C hose assembly

Wear Advice

VHD 50

AMKX 50 Ms

'Camlock' brass steel coupler to EN 14420 - 7 with hose tail and Spannfix clamps

ERV SR:

ERV with inner protection sleeve of stainless steel AISI 316 Ti to prevent abrasion of the rubber liner, i. e. for media containing abrasive components or to avoid cavitation. Please note : The nominal bore is reduced.

Lube oil loading of a ship

TW 75 hose assembly, TW couplings

ELAFLEX Hamburg

Assembling Spannloc hose clamps

DDC-V Dry Disconnect Couplings for various media

tank storage; TW hose assembly

ZVA Slimline 2 GR, special type with bellows, black, guard 3 - side view
