Mobile tank for solvents
hose assembly UTS 50 with MKX 50 SS and VB 50 SS
Storz Safety Couplings Type SHK
upon uncoupling, the safety dust plug first falls into holding claws, relasing an eventual pressure within the system. Only then the dust cap can be fully taken off. - increased protection for the operating personnel. Easy to use, no additional pressure release necessary, slim design, does not build up, no freezing up in the dome section.
ZVA Slimline 2, guard no. 1, black scuffguard, blue product sleeve, SL 16 hose assembly with blue Colour Sleeve
ERV-GS
"Yellow Steel" Rubber Expansion Joints / ship engine room of a ferry
IBC unloading
Coupling of Chemopal chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-adapter RS 60 x 2 SS.
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings; Use of adapters with ACME thread
Chemical manifold
FEP 5O, MannTek DDC-M 5O SS
Aljac Closed Circuit Sampler (CCS), Carter Underwing Nozzle, bonding reel
Airfield refueller
ZVA Slimline 2, black - top view
Slimline 21 blue
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.
ELAFLEX Hamburg
Assembling dispensing hose fitting
Boat refuelling with L.P. Gas
GasGuard nozzle, LPG 16 hose
MK-A 80 SS, TW female coupler with Active Safeguard Lever, VB 80 SS
Pull slider to unlock
Flexible bronze pipe connectors
Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps
Oasis FV103 Fill Valve, NC 104 Nozzle Coupler, CNG bus refuelling
Ship loading various media - STW 150 and UTS 150 hose assemblies
ELAFLEX Hamburg
Delivery trucks, loading ramps
Hose Reel Spring Rewind, ZVA Slimline 2 blue
Pump Safety Break
PSB 16
SG-COAX_Al
Sight Glass, to EN 13617-1, for ZVA Slimline 2 GR with vapour recovery. Installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised fuels.
ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid
and Slimline dispensing hose, black
SPANNLOC bolted Sicherheits Klemmbacken aus aluminium
SC 75 Al
Solvent filling with integrated vapour recovery in the nozzle
ZVA 25 GR, UTS hose assemblies
ERV-G
Ship engine room: 2 Yellow Band Expansion Joints mounted together for extra permissable movement
ZVF 25 overwing refuelling
M 21-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, blue.
ZVA Slimline 2 and ZVA Slimline 2 GR with sight glasses, Slimline hose assemblies
Petrol station, Czech Republic
Vergleich visibility aircraft refuelling hoses - below: "Yellow Band" standard, top: "NEON" new version with reflecting bands
ERV-G Yellow Band rubber expansion joints, pumping system for oil emulsion
MK 50 SSE
TW female coupler. Material: stainless steel with universally resistant PFA coating (red)
