Oasis BV706 ball valves with Code 62 flange and SAE connection, for CNG
Elaflon PTFE 50
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
Elaflex Cam and Groove Couplings ('Camlock'): AMKX 50 EASY
EASYLOC stainless steel coupler to EN 14420 - 7, with lever arrest. Picture shows the version as one-piece coupler with integrated hose tail and Spannfix stainless steel clamp
Hose assemblies and Rubber Expansion Joints for the chemical industry
ERV-GR TA, UTL with DDC, FXD with male thread, Elaflon Plus FEP with foodstuff fitting, Elaflon PTFE with female thrad
ELAFLEX refuelling equipment:
Quality is in the detail.
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Manufacturing nozzle seat
Oasis Engineering Ltd, New Zealand (CNG refuelling products)
Production Picture 22
MC 100 SS female threaded hose coupling with Spannloc clamps
with universal hose UTL 100
BK 3 Ms
Cap with 3" female BSP thread, brass
ZVF 50 helicopter refuelling with HD-C hose assembly
France
ERV-G AF
Suitable for piping systems of aviation refuelling or dispensing vehicles in accordance to EN ISO 1825/EI 1529. Suitable for all aviation fuels.
FGN 3" SS
Flange with male thread, stainless steel
ERV-ROTEX expansion joint, inhouse emergency power generator
VB 50 P, VB 80 P
TW dust plugs of Polyamide
Hose Connection with TW coupling, TSG 3" Sight Glass
MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
FWS composite hoses / hose assemblies
Type FWS PTFE with male threaded fitting, Type FWS PP with Camlock coupling, Type FWS VR with "TW" female coupler MK
Refuelling with ZVA Slimline 2 nozzle
Scuffguard, Product Sleeve and Colour Sleeve in grey special colour
Vehicle refuelling with LPG (L.P. Gas, Autogas, Propane)
GasGuard GG1 ACME nozzle
SFC 38 SSE
Swiveling flange hose coupling with Spannfix clamps. Material: stainless steel with universally resistant PFA coating (red)
Type PCS 38 (Polypal Clean DN 38 mm)
MC 75-3" Ms
Female hose coupling for hoses, brass, with Spannloc clamps
ELAFLEX Hamburg
ELAFLEX stock
ZVA Slimline TD
Automatic nozzle with special seals, for solvents / chemicals
SG 1½" Al
Ssight glass for ZVA 32 nozzles, e.g. for aviation refuelling.
MK-A 80 SS, TW female coupler with Active Safeguard Lever
connected: hose assembly with VKX 75.80 SS
ERV-G ... TW
Aircraft refueller
Urea solution filling, truck: ZVA HV for AdBlue® nozzle
Oasis TH Tank Head Valves, CNG trailer
DAC-V 65, DAC-M 65
Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading - in action
IBC unloading
Female hose coupling MC 38-S60 SS (with Spannfix clamps). Direct connection of a hose assembly to the IBC.
