M 21-1" cr

Female ferrule hose coupling EN 14424, reuasable. Slimline 21 hose, blue.

DAC-V 65, DAC-M 65

Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading - with and without sight glass

TWD coupling seal

LPG 200 / LPG 100

Bunkering hoses for L.P. Gas with SFC flanged hose couplings

Hot stamping process, production TW coupling parts

Elaflex LTW hose assembly, Matterhorn

Supply of the mountain top station via IBC unloading

ZVF 25 with EKG and GKG

Manual nozzle DN 25 for aircraft overwing refuelling, with ground cable assembly, dust cap assembly and AVGAS sticker (decal)

HB 50 ST tar spraying hose

Pressure hose for road construction machines, especially for hot bitumen and heavy heating oil. Temperature range: - 25° C up to + 220° C. Meets EN 13482, Type 2 SB/B (DN 19 and DN 32 analogue).

Hose Assemblies with Flange - Elapac seals

Flange seal: Elapac.

Helicopter refuelling winter / Canada

ZVF 50, HD 50 C NEON

ERV-R 100.16

RED BAND Rubber Expansion Joint for water, drinking water (DVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature range - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.

ZVG 2 K (Korea)

LPG nozzle for vehicle refuelling with liquefied petroleum gas (propane, butane and mixtures) up to 50 l / min. Working pressure 25 bar. Test pressure 40 bar. Burst pressure > 100 bar. Temperature range - 25° up to + 70° C, 'LT'-Type down to - 40° C.

ERV-ROTEX expansion joint, inhouse emergency power generator

Overwing refuelling ZVA 25

HD-C hose assembly

Swivel EA 075 A f. ZVA HV for AdBlue®

new design

ZVA Slimline 2 TMV nozzle for Diesel with DRIP STOP spout

LPG road tanker loading with MannTek DGC Dry Gas Couplings

ZVA Slimline 2 GR, Coax hose assembly

UK

ROTEX 200.10 SS TAS

Rubber Expansion Joint with PTFE lining and PTFE vakuum support ring

ERV Rubber Expansion Joints

Picture 5

Quick Tester GR 92

for the simple Yes / No functioning test of vapour recovery

Slimline 21 red

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

Ship bunkering

HD hose assembly on dispenser vehicle

ZVF 25 with EKG and GKG

Manual nozzle DN 25 for aircraft overwing refuelling, with ground cable assembly, dust cap assembly. NEW: free of non-ferrous metals to JIG rules. Note: yellow chrome plating on swivel is 'free or non-ferrous metal'.

ERV-R 50.16 ZS 2

Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)

M 21-1" NR cr

Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, blue.

ZVG 2 EURO

(Push-In-Coupling) to EN 13760. One-handed operation possible.

ELAFLEX Hamburg

Assembling dispensing hose: marking

ELAPAC FD flat sealing material

2 or 3 mm thickness, available as coil, standard size seal or in custom shape. An elastic flange seal for tank truck and tank plant construction etc., where rough sealing surfaces require a high adaptability, where flange seals should still have good flexibility to avoid pipe fractures or simple sealing materials because little or no force can be used to tighten the joint.

TSVX 50

Hose connectors with double shank of hot stamped brass, with Spannfix safety clamps of hot stamped aluminium.
