ELAFLEX Hamburg
Stock special flanges
Flange seal FD 220-162 of ELAPAC
Anti-Kinking Spiral 'KSS'
The main bending stress area for hose assemblies is directly behind the coupling. To reinforce this area we developed the new Anti-Kinking Spiral 'KSS': suitable for all ELAFLEX hoses, recommended for dynamically strong stressed universal hoses with thermoplastic linings
ARK 19 Safety Break (Hose Break) at LPG Autogas dispenser
Reassembly on site without tools
LNG ship bunkering
DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling
Rose Reel spring rewind white, HD 38 C, ZVF 50
ELAFLEX Hamburg
Commissioning / Pick by Voice
Tank container filling coupling: MK 80-32 SS with VB 80 SS
MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
ERV-G rubber expansion joint
ERV-G AF DN 80, with TW flanges
ElaSil® Silicone hose assemblies DN 13-102
For Pharma, foodstuff and cosmetics industry.
ELS 25 with Camlock Cam Locking Coupling, foodstuff thread and Triclamp.
L.P.Gas unloading of road tanker
LPG 50 hose assembly
Slimline 16 green
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.
Ship bunkering with LNG
towards the end of the bunkering process
Elapharm EPH 25 with EN 1092-1flange fitting, free of dead spaces
SMX 50-2"
Female hose coupling of steel with Spannfix clamps
Production MannTek, Sweden
BD 63 Hose Beads
to EI 1522 standard - notably improve handling as they reduce friction against the tarmac. They additionally protect against hose abrasion. 'BD' Hose Beads are highly break resistant, contain no bolts or nuts, can be easily assembled or disassembled and are suitable for reeling.
Polypal Clean hose
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Swivel assembling
PSB Pump Safety Break for High Hose Dispensers
Picture shows separation of the Slimline hose assembly after a drive-off accident
GasGuard LPG nozzles
GG1E, GG1DN, GG20H, GG30
GasGuard LPG nozzle GG1E
eoconomic type for industrial refueling / attended refueling. Release volume on valve closure: 1,9 cm³.
Stainless steel couplings with PFA coating, type "...SSE"
Surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
Ship bunkering with LNG
Coupling of DCC male and female part DN 50; left hand side CBC 50 Cryogenic Breakaway Coupling
Automatic lathing machine, production of brass swivel parts
HD-C, aircraft refueller
HD-C aircraft refuelling hose
HD 50 C F
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 EURO UL with EA 866 scuffguard, LPG 16 hose
Swivel Flange and hose tail of stailess steel
SF 63.16 SS
ELAFLEX Hamburg
ERV conductivity test
